Capture widget as video in flutter usingFFmpeg package
We want to record a widget's UI as PNG images (frames) and then combine those frames into a video using FFmpeg.
- Capture the widget's UI as PNG images (frames).
- Combine those frames into a video using FFmpeg.
1. Wrapping the Widget
app/main.dart
1final GlobalKey _globalKey = GlobalKey();
2
3
4Widget build(BuildContext context) {
5 return RepaintBoundary(
6 key: _globalKey,
7 child: widget.child,
8 );
9}- RepaintBoundary : This allows you to snapshot the widget's current UI.
- GlobalKey : Used to get access to this widget later during image capture.
2. Capturing a Frame
app/main.dart
1final RenderRepaintBoundary? boundary =
2 _globalKey.currentContext?.findRenderObject() as RenderRepaintBoundary?;
3
4final ui.Image image = await boundary.toImage(pixelRatio: widget.pixelRatio);
5final byteData = await image.toByteData(format: ui.ImageByteFormat.png);
6await File(framePath).writeAsBytes(byteData.buffer.asUint8List());boundary.toImage(...): Takes a screenshot of the widget.pixelRatio: Controls resolution/quality of captured frame.ImageByteFormat.png: Saves it in PNG format (required by FFmpeg).It saves the frame with a sequential name like:
frame_0000.png,frame_0001.png, etc.
3. Scheduling the Captures
app/main.dart
1_timer = Timer.periodic(Duration(milliseconds: 100), (timer) {
2 captureFrame(frameCount, framesDir.path);
3 ...
4});- Runs every 100ms (which means 10 frames per second).
- Continues for the duration you set (widget.duration), collecting all frames.
FFmpeg Magic — Combine Images into Video
app/main.dart
1await FFmpegKit.executeWithArguments([
2 '-y', // Overwrite output if it exists
3 '-framerate', '10', // Input frame rate: 10 FPS
4 '-f', 'image2', // Input format is a series of images
5 '-pattern_type', 'sequence', // Expect a sequence (frame_0000.png)
6 '-start_number', '0', // Start from frame_0000
7 '-i', '.../frame_%04d.png', // Input path (%04d means 4-digit padded number)
8 '-vcodec', 'mpeg4', // Output video codec
9 '-pix_fmt', 'yuv420p', // Pixel format for Android/iOS support
10 '-an', // No audio
11 'output_video.mp4', // Final video file
12]);Explanation of Each FFmpeg Option:
| Flag | Purpose |
|---|---|
-y | Auto overwrite output file if it exists |
-framerate 10 | Read input at 10 frames per second |
-f image2 | Use raw image input format |
-pattern_type sequence | Accept sequential file names (frame_0001.png) |
-start_number 0 | Start from image frame_0000.png |
-i frame_%04d.png | Read frames in order: 0000, 0001, 0002, etc. |
-vcodec mpeg4 | Use MPEG-4 video codec |
-pix_fmt yuv420p | Required format for wide compatibility (especially iOS/Android players) |
-an | Skip audio (you can add later if needed) |
Output Example
Let's say you recorded for 5 seconds at 10 FPS. You'll get:
- 50 PNG images inside
tempDir/frames/ - A single .mp4 file like
output_video.mp4in your temp directory - That video is playable, shareable, and storable, all from a widget & visuals.
What You Can Customize
| Feature | How to change |
|---|---|
Frame rate | Change -framerate and timer interval |
Resolution | Change pixelRatio or scale images before FFmpeg |
Add Audio | Add -i audio.mp3 before -i image, then -shortest |
Export Path | Change outputVideoPathas per your needs |
Summary of FFmpeg Command Flow:
app/main.dart
1PNG images (frame_0000.png, ...)
2 ↓
3FFmpeg processes each frame
4 ↓
5Compress into MP4 with MPEG4 codec
6 ↓
7✅ Final video createdPro TipKeep frame count low and resolution reasonable for better performance!
